Grandstream GWN7802P Enterprise 16-Port Gigabit L2+ Managed PoE/PoE+ Switch with 4 Gigabit SFP Uplink Ports

Grandstream GWN7802P Enterprise 16-Port Gigabit L2+ Managed PoE/PoE+ Switch with 4 Gigabit SFP Uplink Ports



The GWN7800 series are Layer 2+ managed network switches that allow small-to-medium enterprises to build scalable, secure, high performance, and smart business networks that are fully manageable. It supports advanced VLAN for flexible and sophisticated traffic segmentation, advanced QoS for prioritization of network traffic, IGMP Snooping for network performance optimization, and comprehensive security capabilities against potential attacks. The PoE models provide smart dynamic PoE output to power IP phones, IP cameras, Wi-Fi access points and other PoE endpoints. The GWN7800 series can be managed in a number of ways, including the local network controller embedded in the web user interface of the GWN7800 series switch. The series is also supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform. The enterprise-grade GWN7800 series are the ideal managed network switches for small-to-medium businesses.

Key Features & Benefits of the Grandstream GWN7802P Enterprise 16-Port Gigabit L2+ Managed PoE Switch:

  • 16x Gigabit Ethernet Ports with PoE/PoE+ support (IEEE 802.3af/at), 4x Gigabit SFP Ports
  • Smart power control to support dynamic PoE/PoE+ power allocation per port
  • Max. PoE Power Budjet 240W
  • Max Output Power per PoE Port 30W
  • Total non-blocking throughput 20Gbps
  • Switching Capability 40Gbps
  • Forwarding Rate 29.76M packets per second
  • Packet Buffer 4.1MB
  • Forwarding Mode: store-and-forward
  • Integrated Power Supply 270W
  • Multicast: IGMP Snooping, MLD Snooping, MVR
  • DHCP server, DHCP relay, Option 82, 60,160 and 43
  • 1x Console Port
  • 1x tri-color LED for device tracking and status indication,
  • 20x green LEDs for data ports
  • 16x yellow-color LEDs for PoE ports
  • Desktop, wall-mount, or rack-mount (rack-mount brackets included)
  • Operating temperature 0°Cto 45°C, humidity 10-90% RH (Non-condensing)
  • Storage temperature -10°C to 60°C, humidity: 5% to 95% (Non-condensing)
  • 3 Year Warranty


  • 8K static, dynamic and filtering MAC addresses
  • 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN
  • VLAN virtual interface
  • GVRP (pending)
  • 8 link aggregation groups
  • Spanning tree, 64 instances for STP/RTSP/MSTP
SKU: GWN7802P Categories: ,
Weight 1 kg
