Camera
- Image Sensor: 1/4″ CMOS
- Effective Pixels: 1280(H)×720(V), 1MP
- Scanning System: Progressive
- Electronic Shutter Speed: PAL: 1/25~1/100000s, NTSC: 1/30~1/100000s
- Minimum Illumination: 0.05Lux/F2.0 , 30IRE , 0Lux IR on
- S/N Ratio: More than 65dB
- IR Distance: Up to 30m (98feet)
- IR On/Off Control: Auto / Manual
- IR LEDs: 18
Lens
- Lens Type: Fixed lens / Fixed iris:
- Mount Type: Board-in
- Focal Length: 3.6mm (2.8mm Optional)
- Max Aperture: F2.0
- Angle of View: H: 60° (83.4°)
- Focus Control: N/A
- Close Focus Distance: 600mm (500mm)
- Rotation: 0° ~ 360°
Video
- Resolution: 720P (1280×720)
- Frame Rate: 25/30fps@720P
- Video Output: 1-channel BNC high definition video output / CVBS video output (Can switch)
- Day/Night: Auto (ICR) / Manual
- OSD Menu: Multi-language
- BLC Mode: BLC / HLC / DWDR
- WDR: DWDR
- Gain Control: AGC
- Noise Reduction: 2D
- White Balance: Auto / Manual
- Smart IR: Auto / Manual
Interface
- Audio Interface: N/A
Eelectrical
- Power Supply: 12V DC ±25%
- Power Consumption: Max 3.8W (12V DC, IR on)
Construction
- Casing: Aluminium
- Dimensions: 164.7mm×70mm×71.6mm (6.48″×2.76″×2.82″)
- Net Weight: 0.35kg (0.77lb)
- Gross Weight: 0.44kg (0.97lb)
- Warranty: 3 Years
